Zhongyang Sams Plate Bending Rolls

China W11SNC-60x3000 Plate Bending Roll


New, China W11SNC-60x3000 Plate Bending Roll

  • Rolling Thickness 60 x 3000mm (at dia 2500mm)
  • Prebending Thickness 50 x 3000mm (at dia 2500mm)
  • Top roll pressure 690 Ton
  • Plate width 3000mm
  • Top roll diameter 650mm
  • Bottom rolls diameter 380mm
  • Material 42CrMo
  • Hardness 260-300 HB
  • Distance between bottom rolls center-to-center 700mm
  • Diameter of supporting roller 380mm
  • Rolling speed 3.5 m/min
  • Tor roll: Descending speed 120 mm/min; ascending speed 200 mm/min
  • Top roll horizontal moving speed 100mm/min
  • Top roll accuracy: Synchronous ± ≤0.2mm; Moving ± ≤0.2mm; Re-position ± ≤0.2mm
  • Plate yield limit 245 Mpa
  • Main motor 75 Kw
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used plate bending rolls (plate rolls, plate rolling machine, plate rollers, plate bender, plate bending machine, bending rollers machine, bending machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
