New, Sams B3 1521 3-Roll Plate Bending Machine
- Rolling capacity (cold) 15mm (at diameter 1075mm)
- Prebending capacity (cold) 12mm (at diameter 1075mm)
- Yield strength 260 N/mm2
- Cone capacity by continuous rolling = 60% of prebending thickness
- Cone capacity by pressing = 100% of prebending thickness
- Length of rolls 1500mm
- No. of rolls 3
- Top roll diameter 215mm
- Side rolls diameter 195mm
- Powered driving rolls 3
- Surface speed compensation: automatic by hydraulic unit
- Rolling speed 5 mt/min
- Rolls movement adjustment: hydraulic
- Power ES 10 HP
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
