Zhongyang Sams Plate Bending Rolls


Sams B3 1615S 3-Roll Plate Bending Machine

NHRBK047:

New, Sams B3 1615S 3-Roll Plate Bending Machine

  • Length of rolls 1550mm
  • Rolling capacity (cold) 7mm (at dia 650mm)
  • Prebending capacity (cold) 6mm (at dia 650mm)
  • Rolling capacity (cold) 6mm (at dia 165mm)
  • Prebending capacity (cold) 4mm (at dia 165mm)
  • Yield strength 260 N/mm2
  • Cone capacity by continuous rolling: 60% of prebending thickness
  • Cone capacity by pressing: 100% of prebending thickness
  • No. of rolls 3
  • Top roll diameter 130mm
  • Bottom rolls diameter 150mm
  • Powered driving rolls 3
  • Hydraulic motors: 3 (directly splined on the rolls shaft)
  • Surface speed: automatic by hydraulic unit
  • Rolling speed 5 mt/min
  • Rolls movement adjustment: hydraulic
  • Rolls material: high resistance alloy forged steel
  • Main motor ES 5 HP
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used plate bending rolls (plate rolls, plate rolling machine, plate rollers, plate bender, plate bending machine, bending rollers machine, bending machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
