Zhongyang Sams Radial Drill

China Czech Z3032 x 10/1 Radial Drill


New, China Czech Z3032 x 10/1 Radial Drill

  • Maximum drilling diameter 32mm
  • Distance between spindle axis & column 300 - 1000mm
  • Spindle travel 280mm
  • Distance between spindle nose and working surface of base plate 205 - 985mm
  • Spindle taper No. 4
  • Range of spindle speeds 32 - 2500rpm
  • Number of spindle speeds 16
  • Range of spindle feeds 0.08 - 1 mm/r
  • Number of spindle feeds 8
  • Table size 450 x 600mm
  • Arm length 1420mm
  • Power of main motor 2.2 kW
  • Overall Dimensions: 1,760 mm (L) x 800 mm (W) x 2,300 mm (H)
  • Weight approximately 1.6 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used radial drill (radial drill, radial drilling machine, radial drill press, radial arm drilling machine, radial arm drill press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
