Zhongyang Sams Radial Drill

China Z3040 x 8/1 Radial Drill


New, China Z3040 x 8/1 Radial Drill

  • Max drilling capacity 40mm
  • Distance between spindle axis and column 300-800mm
  • Diameter of column 240mm
  • Spindle taper MT4
  • Spindle travel 280mm
  • Spindle speed range 32-2500 RPM (16 steps)
  • Spindle feeds 0.10 - 1.25 mm/r (8 steps)
  • Max distance between spindle nose to working surface of base 220-800mm
  • Dimension of worktable 600 x 450 x 450 mm
  • Dimension of base 1710 x 800 x 160 mm
  • Main motor 2.2 kw
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used radial drill (radial drill, radial drilling machine, radial drill press, radial arm drilling machine, radial arm drill press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
