Zhongyang Sams Pillar Drill


China Z5040A Vertical Drilling Machine

NDPTT007:

New, China Z5040A Vertical Drilling Machine

  • Max drilling capacity 40mm
  • Max tapping capacity M24
  • Distance from spindle axis to generating line of column 360mm
  • Max distance from spindle nose to worktable surface 600mm
  • Max distance from spindle nose to worktable surface of base 1215mm
  • Max spindle travel 180mm
  • Max adjustment of worktable and table rest 560mm
  • Swivel of table and table reat ±45°
  • Spindle bore taper Morse No. 4
  • Spindle speed 42-2050 r/min (12 steps)
  • Spindle feed range 0.07, 0.15, 0.26, 0.4 mm/r (4 steps)
  • Column diameter 160mm
  • Effective working area of table: (LxW) 580x450mm
  • Effective working area of base plate: (LxW) 820x550mm
  • Dimension of T-slot of table and base plate: 2-14mm; 2-16mm
  • AC motor: 2.2/2.8 kw; 960/1450 r/min
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used pillar drill (pillar drill, pillar drilling machine, column drill machine, column drilling machine, vertical drill stand, vertical drilling machine, drill press, pedestal drilling machine, pedestal drill press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
