China CK5126/1 CNC Single Column Vertical Lathe

NBVDB037:

New, China CK5126/1 CNC Single Column Vertical Lathe

  • Max cutting diameter 2600mm
  • Table diameter 2000/2300mm
  • Max height of workpiece 1500mm
  • Max weight of workpiece 10 ton
  • Max torque of table 37 KN.m
  • Range of table speeds 1.2 - 40 r/min, off 16
  • Max cutting force of rail head 22 KN, side head 18 KN
  • Swivel of rail head ±30°
  • Range of feed rates 0.8 - 86 mm/min, off 12
  • Horizontal travel of rail head 1600mm
  • Ram travel of rail head 1000mm
  • Ram horizontal travel of side head 730mm
  • Vertical travel of side head 1180mm
  • Rapid traverse of tool heads 1800 mm/min
  • Rise-and-fall speed of beam 440mm
  • Height of tool bar section (WxH): 30 x 40 mm
  • Main motor 37 kW
  • Overall Dimensions: 3,300 mm (L) x 4,000 mm (W) x 3,500 mm (H)
  • Weight approximately 20 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used vertical boring machine (vtl, vbm, vertical borer, vertical lathe machine, vertical boring machine, vertical boring mills, vertical turret lathe machine, vertical turning lathe, vertical boring mill), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
