Horizontal Borer

NBHSY112:

New, China Czech TH6516 CNC Horizontal Boring & Milling Machine

• China Czech CNC Hor. Boring & Milling Machine
• Model TH6516(A)
• Spindle Diameter 160 mm
• Table Size 1600x1800 mm (Opt. 2000x2500)
• Max Load on Table 10000 kg (Opt. 20000)
• Worktable T-Slot 28 mm X 9
• Spindle Taper ISO7:24 No.50
• Spindle Speed 5-1500 RPM
• Max Torque 3500/4800 Nm
• Distance Between Spindle Axis And Table Top 100-1700 mm
• Min Distance Between Spindle End And Table 17 mm
• Table X Traverse 2500 mm
• Headstock Y Travel 2000 mm (Opt. 2500, 3500)
• Column Z Travel 2000 mm (Opt. 3000)
• Spindle W Travel 1000 mm
• Rotation B of Rotary Table 360 Deg
• Traverse Speed: X / Y / Z 1-6000 mm/min, W 1-3000 mm/min, B 0-1 r/min
• Rapid Traverse: X / Y / Z 9 m/min, W / U 3 m/min, B 1 r/min
• Tool Magazine Capacity 40
• Power of Main Motor 37 kW (51 kW for 30 min continuous)
• AC Servomotors Rated Torque: X/Z/W/B 38 Nm, Y 55 Nm
• Positioning Accuracy X / Y / Z: +/- 0.008 mm Over Full Length (Opt. +/- 0.005)
• Positioning Accuracy B (4 X 90 Deg): +/- 7.5" (Opt. +/- 2")
• Repeatability X / Y / Z: +/- 0.005 mm (Opt. +/- 0.0025), B (4 X 90 Deg): +/- 2"
• CNC System Siemens 840D (Opt. Fanuc 18i)
• Total Power 70 kVA
• Overall Dimensions: 6,800 mm (L) x 6,230 mm (W) x 4,930 mm (H)
• Weight approximately 40 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you are considering inexpensive machinery, call us for China machinery.
